-->> Intel NUC P14E Laptop Kit CMCN1CC with 12th Generation Intel Core Processors i5-1240P i7-1255U i7-1260P <<--

Intel® NUC P14E Laptop Kit
Intel® NUC P14E Laptop Kits feature a premium-quality design and Intel's latest processors and technology.

Intel® NUC P14E Laptop Kit - CMCN1CC
Intel® NUC P14E Laptop Kit - CMCN1CC

Intel® Core™ i5-1240P Processor (12M Cache, up to 3.30/4.40 GHz, with IPU) Cores 12 Threads 16 Threads Intel Iris Xe Graphics 1.30 GHz
Intel® Core™ i7-1255U Processor (12M Cache, up to 3.50/4.70 GHz, with IPU) Cores 10 Threads 12 Threads Intel Iris Xe Graphics 1.25 GHz
Intel® Core™ i7-1260P Processor (18M Cache, up to 3.40/4.70 GHz, with IPU) Cores 12 Threads 16 Threads Intel Iris Xe Graphics 1.40 GHz

Intel® Core™ i5-1240P Processor
12M Cache, up to 4.40 GHz
Product Collection
12th Generation Intel® Core™ i5 Processors
Code Name Products formerly Alder Lake
Vertical Segment Mobile
Processor Number i5-1240P
Status Launched
Launch Date Q1'22
Lithography Intel 7
CPU Specifications
Total Cores 12
# of Performance-cores 4
# of Efficient-cores 8
Total Threads 16
Max Turbo Frequency 4.40 GHz
Performance-core Max Turbo Frequency 4.40 GHz
Efficient-core Max Turbo Frequency 3.30 GHz
Cache 12 MB Intel® Smart Cache
Processor Base Power 28 W
Maximum Turbo Power 64 W
Minimum Assured Power 20 W
Max Memory Size (dependent on memory type) 64 GB
Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Up to LPDDR5 5200 MT/s
Up to LPDDR4x 4267 MT/s
Processor Graphics ‡ Intel® Iris® Xe Graphics eligible
Graphics Max Dynamic Frequency 1.30 GHz
Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1

Intel® Core™ i7-1260P Processor
18M Cache, up to 4.70 GHz
Product Collection 12th Generation Intel® Core™ i7 Processors
Code Name Products formerly Alder Lake
Vertical Segment Mobile
Processor Number i7-1260P
Status Launched
Launch Date Q1'22
Lithography Intel 7
Total Cores 12
# of Performance-cores 4
# of Efficient-cores 8
Total Threads 16
Max Turbo Frequency 4.70 GHz
Performance-core Max Turbo Frequency 4.70 GHz
Efficient-core Max Turbo Frequency 3.40 GHz
Cache 18 MB Intel® Smart Cache
Processor Base Power 28 W
Maximum Turbo Power 64 W
Minimum Assured Power 20 W
Max Memory Size (dependent on memory type) 64 GB
Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Up to LPDDR5 5200 MT/s
Up to LPDDR4x 4267 MT/s
Processor Graphics Intel® Iris® Xe Graphics eligible
Graphics Max Dynamic Frequency 1.40 GHz
Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1

Intel® NUC P14E Laptop Kit - CMCN1CC

Intel® NUC P14E Laptop Element - CMCN1CC
Essentials
Product Collection Intel® NUC Laptop Elements
Code Name Products formerly Camden County
Status Launched
Launch Date Q3'21
Supported Operating Systems
Windows 11*, Windows 10*, Linux*
Board Form Factor
U-series Element Carrier Board
Internal Drive Form Factor
M.2 SSD
# of Internal Drives Supported 1
Intel vPro® Platform Eligibility Yes
Warranty Period 2 yrs
Use Conditions PC/Client/Tablet
Recommended Customer Price $674.10
Supplemental Information
Embedded Options Available No
Memory & Storage
Included Storage
Requires m.2 storage module
Memory Types
Requires NUC Compute Element (U)
Processor Graphics
Graphics Output 1x HDMI 2.0b, 1x miniDP 1.4a, 1x USB-C DP 1.4a
Expansion Options
PCI Express Configurations PCIe x4 Gen 4 (m.2)
M.2 Card Slot (storage) 1
I/O Specifications
# of USB Ports 3
USB Configuration
2x USB 3.2 Gen2, 1x Thunderbolt™ 4
Integrated LAN
Intel® Ethernet Connection I219-LM
# of Thunderbolt™ Ports
1x Thunderbolt™ 4
Package Specifications
Chassis Dimensions
304x230x16.5mm
Advanced Technologies
Intel® Optane™ Memory Supported Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel vPro® Platform Eligibility Yes
Intel® HD Audio Technology Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Platform Trust Technology (Intel® PTT) Yes
Security & Reliability
Intel vPro® Eligibility
Intel vPro® Platform
Intel® AES New Instructions Yes

Processor Graphics ‡ Intel® Iris® Xe Graphics eligible
IPS panel resolution 3000x2000 400nits
16GB LPDDR5-5200Mhz
Chassis Dimensions 303.6mm x 229.4mm x 16.55mm

Order Information
Intel NUC P14E Laptop Kit CMCN1CC Alder Lake i5-1240P 16GB LPDDR5 no M.2 SSD 13.9inch IPS FHD 3000x2000, non-touch, Midnight Black
Intel NUC P14E Laptop Kit CMCN1CC Alder Lake i7-1255U 16GB LPDDR5 no M.2 SSD 13.9inch IPS FHD 3000x2000, touch, Midnight Black
Intel NUC P14E Laptop Kit CMCN1CC Alder Lake i7-1260P 16GB LPDDR5 no M.2 SSD 13.9inch IPS FHD 3000x2000, touch, Midnight Black

optional accessories: Infrared keybaord and 2.4G/RF wireless keyboard with mouse (trackball or touchpad)
Infrared Keyboard with Rubber Trackball K809	2.4G/RF Wireless Keyboard with Touchpad K8C	2.4G/RF Wireless Keyboard with Touchpad K8
