-->> Mini PC Intel Original NUC 10 Performance Kit Frost Canyon NUC10i3FNK with 10th Generation Intel Core Processors i3-10110U <<--

Intel® NUC 10 Performance Kit - NUC10i3FNK
Intel® Core™ i3-10110U Processor (4M Cache, Up to 4.10 GHz)
M.2 Drive Internal Drive Form Factor
HDI 2.0b; USB-C (DP1.2) Graphics Output
117 x 112 x 36mm Chassis Dimensions

The Intel® NUC kit features a customizable board and chassis that are ready to accept a wide variety of memory, storage, and operating systems. For businesses, students, educators, and DIYers.

NUC10i3FNK
# of Internal Drives Supported 1
M.2 Drive
Chassis Dimensions 117 x 112 x 36mm

Technical Specifications
Essentials
StatusLaunched
Product CollectionIntel® NUC Kit with 10th Generation Intel® Core™ Processors
Code Name Products formerly Frost Canyon
Launch Date Q4'19
Supported Operating SystemsWindows 10, 64-bit*
Board NumberNUC10i3FNB
Board Form FactorUCFF (4" x 4")
SocketSoldered-down BGA
Internal Drive Form Factor M.2 Drive
# of Internal Drives Supported 1

Technical Specifications
Essentials
StatusLaunched
Product CollectionIntel® NUC Kit with 10th Generation Intel® Core™ Processors
Launch Date Q4'19
Supported Operating SystemsWindows 10, 64-bit*
Board NumberNUC10i3FNB
Board Form FactorUCFF (4" x 4")
SocketSoldered-down BGA
Internal Drive Form FactorM.2
# of Internal Drives Supported 1
Lithography 14 nm
TDP 25 W
DC Input Voltage Supported19 VDC
Processor IncludedIntel® Core™ i3-10110U Processor
Warranty Period 3 yrs
Supplemental Information
Embedded Options Available No
DescriptionOther features: Includes far-field quad array microphones
Memory & Storage
Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4-2666 1.2V SO-DIMM
Max # of Memory Channels 2
Max Memory Bandwidth 42.6 GB/s
Max # of DIMMs 2
ECC Memory Supported ‡ No
Processor Graphics ‡ Intel® UHD Graphics for 10th Gen Intel® Processors
Integrated Graphics ‡ Yes
Graphics Output HDI 2.0b; USB-C (DP1.2)
# of Displays Supported ‡3
Expansion Options
PCI Express Revision Gen3
PCI Express Configurations ‡ M.2 slot with PCIe X4 lanes
Removable Memory Card Slot SDXC with UHS-II support
M.2 Card Slot (storage) 22x42/80
I/O Specifications
# of USB Ports7
USB Configuration2x front (Type-A, Type-C) and 3x rear USB 3.1 Gen2 (2x Type-A, Type-C); 2x USB 2.0 via internal headers
USB Revision 2.0, 3.1 Gen2
USB 2.0 Configuration (External + Internal)0 + 2
USB 3.0 Configuration (External + Internal)2B 2F + 0
Total # of SATA Ports 2
Max # of SATA 6.0 Gb/s Ports2
RAID Configuration 2.5" HDD/SSD + M.2 SATA SSD (RAID-0 RAID-1)
Audio (back channel + front channel)7.1 digital (HDI mDP); L+R mic (F)
Integrated LAN Intel® Ethernet Connection I219-V
Integrated Wireless‡Intel® Wi-Fi 6 AX201
Integrated BluetoothYes
Consumer Infrared Rx Sensor Yes
Additional Headers CEC, 2x USB2.0, FRONT_PANEL, RGB
# of Thunderbolt™ Ports 1x Thunderbolt™ 3
Package Specifications
Chassis Dimensions117 x 112 x 51mm
Advanced Technologies
Intel® Optane™ Memory Supported ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel vPro® Platform Eligibility ‡ No
TPM No
Intel® HD Audio Technology Yes
Intel® Rapid Storage Technology Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Platform Trust Technology (Intel® PTT) Yes
Security & Reliability
Intel® AES New Instructions Yes

optional accessories: Infrared keybaord and 2.4G/RF wireless keyboard with mouse (trackball or touchpad)
Infrared Keyboard with Rubber Trackball K809	2.4G/RF Wireless Keyboard with Touchpad K8C	2.4G/RF Wireless Keyboard with Touchpad K8
