-->> Mini PC Intel Original NUC Kit Grass Canyon NUC5PGYH with Intel Pentium processor N3700 2G RAM 32G SSD Windows 10 Home x64 <<--

https://ark.intel.com/content/www/us/en/ark/products/85254/intel-nuc-kit-nuc5cpyh.html
Intel® NUC Kit NUC5CPYH
Board Number NUC5CPYB
Intel® Celeron® Processor N3060 (2M Cache, up to 2.48 GHz)
# of Cores 2
Total Threads 2

https://ark.intel.com/content/www/us/en/ark/products/87740/intel-nuc-kit-nuc5ppyh.html
Intel® NUC Kit NUC5PPYH
Board Number NUC5PPYB
Intel® Pentium® Processor N3700 (2M Cache, up to 2.40 GHz)
# of Cores 4
Total Threads 4

https://ark.intel.com/content/www/us/en/ark/products/88065/intel-nuc-kit-nuc5pgyh.html
Intel® NUC Kit NUC5PGYH
Board Number NUC5PGYB
Intel® Pentium® Processor N3700 (2M Cache, up to 2.40 GHz)
# of Cores 4
Total Threads 4
Included Memory 2 GB
Other features: 2GB DDR3L SO-DIMM; 32GB eMMC on-board; Windows® 10, 64-bit Home pre-installed.

Intel® NUC Kit NUC5PGYH
Intel® Pentium® Processor N3700 (2M Cache, up to 2.40 GHz)
DDR3L-1333/1600 1.35V SO-DIMM
Internal Drive Form Factor 2.5" Drive
Graphics Output VGA (HDB15); HDI 1.4b
Pre-Installed Operating System Windows 10 Home x64

Technical Specifications
Essentials
Status Launched
Launch Date Q3'15
Expected Discontinuance See Roadmap
Board Form Factor UCFF (4" x 4")
Socket Soldered-down BGA
Internal Drive Form Factor 2.5" Drive
# of Internal Drives Supported 1
Embedded Storage 32 GB
Lithography 14 nm
TDP 6 W
DC Input Voltage Supported 12-19 VDC
Pre-Installed Operating System Windows 10 Home x64
Processor Included
Intel® Pentium® Processor N3700 (2M Cache, up to 2.40 GHz)
Warranty Period 3 yrs
Supplemental Information
Embedded Options Available No
Description
Other features: 2GB DDR3L SO-DIMM; 32GB eMMC on-board; Microsoft Windows 10 pre-installed. Includes SDXC card slot
Memory Specifications
Pre-Installed Memory 2 GB
Max Memory Size (dependent on memory type) 8 GB
Memory Types DDR3L-1333/1600 1.35V SO-DIMM
Max # of Memory Channels 1
Max Memory Bandwidth 12.8 GB/s
Max # of DIMMs 1
ECC Memory Supported ‡ No
Graphics Specifications
Integrated Graphics ‡ Yes
Graphics Output VGA (HDB15); HDI 1.4b
Intel® Clear Video Technology Yes
# of Displays Supported ‡ 2
Expansion Options
PCI Express Revision Gen2
PCI Express Configurations ‡
M.2 slot with PCIe X1 lane
Removable Memory Card Slot
SDXC with UHS-I support
M.2 Card Slot (wireless) 22x30
I/O Specifications
USB Revision 2.0, 3.0
# of USB Ports 6
USB 2.0 Configuration (External + Internal) 0 + 2
USB 3.0 Configuration (External + Internal) 2B 2F + 0
Total # of SATA Ports 1
Max # of SATA 6.0 Gb/s Ports 1
Audio (back channel + front channel)
7.1 digital (HDI); L+R+mic (F); L+R+TOSLINK (R)
Integrated LAN 10/100/1000
Integrated Wifi Intel® Wireless-AC 3165 + BT 4.2
Integrated Bluetooth Yes
Consumer Infrared Rx Sensor Yes
S/PDIF Out Connector TOSLINK
Additional Headers 2x USB2.0, AUX_PWR
Advanced Technologies
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® vPro™ Technology ‡ No
TPM No
Intel® HD Audio Technology Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Platform Trust Technology (Intel® PTT)

optional accessories: Infrared keybaord and 2.4G/RF wireless keyboard with mouse (trackball or touchpad)
Infrared Keyboard with Rubber Trackball K809	2.4G/RF Wireless Keyboard with Touchpad K8C	2.4G/RF Wireless Keyboard with Touchpad K8
