-->> Mini PC Intel Original NUC Kit Baby Canyon NUC7i3BNH with 7th Generation Intel Core Processors i3-7100U <<--
-->> Mini PC Intel Original NUC Kit Baby Canyon NUC7i5BNH with 7th Generation Intel Core Processors i5-7260U <<--
-->> Mini PC Intel Original NUC Kit Baby Canyon NUC7i7BNH with 7th Generation Intel Core Processors i7-7567U <<--

Intel® NUC Kit NUC7i3BNH
Intel® Core™ i3-7100U Processor (3M Cache, 2.40 GHz)
DDR4-2133 1.2V SO-DIMM
Graphics Output HDI 2.0a; USB-C (DP1.2)
Internal Drive Form Factor M.2 and 2.5" Drive

Intel® NUC Kit NUC7i5BNH
Intel® Core™ i5-7260U Processor (4M Cache, up to 3.40 GHz)
DDR4-2133 1.2V SO-DIMM
Graphics Output HDI 2.0a; USB-C (DP1.2)
Internal Drive Form Factor M.2 and 2.5" Drive

Intel® NUC Kit NUC7i7BNH
Intel® Core™ i7-7567U Processor (4M Cache, up to 4.00 GHz)
DDR4-2133 1.2V SO-DIMM
Graphics Output HDI 2.0a; USB-C (DP1.2)
Internal Drive Form Factor M.2 and 2.5" Drive

Essentials
Product Collection Intel® NUC Kits
Code Name Products formerly Baby Canyon
Status Launched
Launch Date Q1'17
Expected Discontinuance See Roadmap
Board Form Factor UCFF (4" x 4")
Socket Soldered-down BGA
Internal Drive Form Factor M.2 and 2.5" Drive
# of Internal Drives Supported 2
Lithography 14 nm
TDP 15W(i3，i5) 28W(i7)
DC Input Voltage Supported 12-19 VDC
Processor Included Intel® Core™ i3-7100U Processor (3M Cache, 2.40 GHz)
Processor Included Intel® Core™ i5-7260U Processor (4M Cache, up to 3.40 GHz)
Processor Included Intel® Core™ i7-7567U Processor (4M Cache, up to 4.00 GHz)
Warranty Period 3 yrs

Supplemental Information
Embedded Options Available No
Description Other features: Includes Thunderbolt 3 (40Gbps) USB 3.1 Gen 2 (10Gbps) and DP 1.2 via USB-C; also includes SDXC card slot, dual microphones

Memory Specifications
Max Memory Size (dependent on memory type) 32 GB
Memory Types DDR4-2133 1.2V SO-DIMM
Max # of Memory Channels 2
Max Memory Bandwidth 34.1 GB/s
Max # of DIMMs 2
ECC Memory Supported ‡ No

Graphics Specifications
Integrated Graphics ‡ Yes
Graphics Output HDI 2.0a; USB-C (DP1.2)
# of Displays Supported ‡ 3

Expansion Options
PCI Express Revision Gen3
PCI Express Configurations ‡ M.2 slot with PCIe x4 lanes
Removable Memory Card Slot SDXC with UHS-I support
M.2 Card Slot (storage) 22x42/80

I/O Specifications
USB Revision 2.0, 3.0
# of USB Ports 6
USB 2.0 Configuration (External + Internal) 0 + 2
USB 3.0 Configuration (External + Internal) 2B 2F + 0
Total # of SATA Ports 2
Max # of SATA 6.0 Gb/s Ports 2
RAID Configuration 2.5" HDD/SSD + M.2 SATA/PCIe SSD (RAID-0 RAID-1)
Audio (back channel + front channel) 7.1 digital (HDI mDP); L+R+mic (F)
Integrated LAN 10/100/1000
Integrated Wifi Intel® Wireless-AC 8265 + BT 4.2
Integrated Bluetooth Yes
Consumer Infrared Rx Sensor Yes
Additional Headers CEC, 2x USB2.0, FRONT_PANEL

Package Specifications
Low Halogen Options Available See MDDS

Advanced Technologies
Intel® Optane™ Memory Supported ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® vPro™ Technology ‡ No
TPM No
Intel® HD Audio Technology Yes
Intel® Rapid Storage Technology Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Platform Trust Technology (Intel® PTT) Yes

Intel® Data Protection Technology
Intel® AES New Instructions Yes

optional accessories: Infrared keybaord and 2.4G/RF wireless keyboard with mouse (trackball or touchpad)
Infrared Keyboard with Rubber Trackball K809	2.4G/RF Wireless Keyboard with Touchpad K8C	2.4G/RF Wireless Keyboard with Touchpad K8
