-->> Mini PC Intel NUC9 Extreme Kit Quartz Canyon NUC9V7QNX with 9th Generation Intel Core Processors i7-9850H <<--

Intel® NUC 9 Extreme Kit - NUC9V7QNX


Essentials
Product Collection Intel® NUC Kit with 9th Generation Intel® Core™ Processors
Code Name Products formerly Quartz Canyon
Status Launched
Launch Date Q1'20
Supported Operating Systems Windows 10, 64-bit*
Board Number NUC9V7QNB
Board Form Factor PCIe
Internal Drive Form Factor M.2 SSD
# of Internal Drives Supported 3
Lithography 14 nm
Board Chipset Mobile Intel® CM246 Chipset
Processor Included Intel® Core™ i7-9850H Processor (12M Cache, up to 4.60 GHz)
Intel vPro® Platform Eligibility Yes
# of Cores 6
# of Threads 12
Processor Base Frequency 2.60 GHz
Max Turbo Frequency 4.60 GHz
Warranty Period 3 yrs
Supplemental Information
Embedded Options Available No


Memory & Storage
Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4 2666 MHz 1.2V SO-DIMM
Max # of Memory Channels 2
Max Memory Bandwidth 42.6 GB/s
Max # of DIMMs 2
ECC Memory Supported No

Processor Graphics
Integrated Graphics Yes
Graphics Output 2x Thunderbolt 3, HDI 2.0a
# of Displays Supported 3
Discrete Graphics Via PCIe add-in card(s)

Expansion Options
PCI Express Revision Gen3
PCI Express Configurations
2x M.2 PCIe X4 slots (PCH), 1x M.2 PCIe X4 slot (CPU)
Double-wide PCIe X16 (CPU) slot shared with PCIe X4 (CPU) slot, 8" max card length
PCIe x4 Gen 3 1
PCIe x16 Gen 3 1
Removable Memory Card Slot
SDXC with UHS-II support
M.2 Card Slot (storage)
2x via PCH + 1x via CPU (NVMe)

I/O Specifications
# of USB Ports 11
USB Configuration
4x rear USB 3.1g2, 2x Thunderbolt 3 (USB 3.1g2), 2x front USB 3.1g2, 2x USB 2.0 via internal headers, 1x USB 2.0 internal
USB Revision 3.1 Gen2, 2.0
USB 2.0 Configuration (External + Internal)
3x int.
Total # of SATA Ports 3
Max # of SATA 6.0 Gb/s Ports 3
RAID Configuration 2x M.2 SATA/PCIe SSD, SATA header (RAID-0 RAID-1)
Audio (back channel + front channel) 7.1 digital; L+R+mic (F); L+R+TOSLINK (R)
Integrated LAN Intel® Ethernet Connection i219-LM and i210-AT
Integrated Wireless Intel® Wi-Fi 6 AX200
Integrated Bluetooth Yes
S/PDIF Out Connector TOSLINK
Additional Headers CEC, 2x USB2.0, FRONT_PANEL
# of Thunderbolt™ Ports 2x Thunderbolt™ 3

Package Specifications
Chassis Dimensions 238 x 216 x 96mm
Advanced Technologies
Intel® Optane™ Memory Supported Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel vPro® Platform Eligibility Yes
TPM Yes
TPM Version Discrete 2.0
Intel® Rapid Storage Technology Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Platform Trust Technology (Intel® PTT) Yes

optional accessories: Infrared keybaord and 2.4G/RF wireless keyboard with mouse (trackball or touchpad)
Infrared Keyboard with Rubber Trackball K809 2.4G/RF Wireless Keyboard with Touchpad K8C 2.4G/RF Wireless Keyboard with Touchpad K8
